HEY THERE, HARRISON HERE - FOUNDER OF HANDLWORKS.

I want to thank you for coming on board with us. We think the ebike powertrain should be indefinitely upgradeable and flexible to your needs - everything we build is a step in that direction. Thank you for supporting our grand vision of the ebike space.
Go build your ebikes!

-Harrison

KILOWATT OVERVIEW

DOWNLOAD FLASH

MUST BE DOWNLOADED TO YOUR MOBILE DEVICE.

SUPER73 R/S SERIES

48V STOCK

Last updated: 8/5/25

This section is for the following setup:

  • BAC855
  • Stock motor
  • Stock battery
Stock flash (8/5/25):

DOWNLOAD 48V STOCK

Uses time-based foldbacks. You will see Kilowatt messages of "motor over-temp" - this is NORMAL! This flash should avoid most cutouts on stock batteries.

If you've only installed the BAC855, this flash will work for you.

48V DUAL

Last updated: 10/17/25

This flash is for the following setup:

  • BAC855
  • Dual stock 48V batteries
  • Stock motor

DOWNLOAD 48V DUAL

This is the flash you need if you've upgraded your stock vehicle with a dual 48V battery setup. Your batteries are set up in parallel, and you now can deliver up to 80A continuous of current at 48V nominal voltage. You'll get more power and acceleration by uploading this flash.

NOTE: Folks have been having trouble with the Chi splitter setup. We think it's because they come under-built with 30A fuses in-line. Recommend replacing with 50A fuses to get the appropriate amount of power.

Flash without throttle, for EU (9/4/24):

DOWNLOAD DUAL 48V PAS ONLY

60V UPGRADE

Last updated: 09/29/25

This flash is for the following setup:

  • BAC855
  • Stock motor
  • 60V battery, 75A max current

DOWNLOAD 60V

This is the flash you need if you've upgraded your battery to a 60V battery. The peak power is set to 6500W. You'll get above 40mph, and more power and acceleration by uploading this flash.

60V UPGRADE (BAC2000)

Last updated: 10/09/25

This flash is for the following setup:

  • BAC2000
  • Stock motor
  • 60V battery, 80A continuous current

DOWNLOAD 60V BAC2000

This is the flash that comes stock on a BAC2000 for R/S Series. It requires an adequately powerful 60V battery, along with a stock motor.

SUPER73 ZX

48V STOCK

Last updated: 8/5/25

This section is for the following setup:

  • BAC855
  • Stock motor
  • Stock battery

DOWNLOAD 48V STOCK

If you've only installed the BAC855, this flash is for you. It is the flash that is pre-loaded on a BAC855 ZX kit.

Uses time-based foldbacks. You will see Kilowatt messages of "motor over-temp" - this is NORMAL!

Works with 500, 750, and 1000 batteries.

48V DUAL

Last updated: 10/2/25

This flash is for the following setup:

  • BAC855
  • Dual stock 48V batteries
  • Stock motor

DOWNLOAD 48V DUAL ZX

This is the flash you need if you've upgraded your stock vehicle with a dual 48V battery setup. Your batteries are set up in parallel, and you now can deliver up to 60A continuous of current at 48V nominal voltage. You'll get more power and acceleration by uploading this flash.

60V UPGRADE

Last updated: 8/25/25

This flash is for the following setup:

  • BAC855
  • Stock motor
  • 60V battery, 80A max current

DOWNLOAD 60V

This is the flash you need if you've upgraded your battery to a 60V battery. The peak power is set to 6500W. You'll get above 40mph, and more power and acceleration by uploading this flash.

SUPER73-Z MIAMI

48V STOCK

Last updated: 8/8/25

This section is for the following setup:

  • BAC855
  • Stock motor
  • Stock battery

DOWNLOAD 48V STOCK

If you've only installed the BAC855, this flash is for you. It is the flash that is pre-loaded on a BAC855 Z Miami kit.

First flash that uses time-based foldbacks - you will see messages in Kilowatt that show "motor over-temperature" - this is NORMAL!

60V UPGRADE

Last updated: 08/25/25

This flash is for the following setup:

  • BAC855
  • Stock motor
  • 60V battery, 75A continuous current

DOWNLOAD 60V

This is the flash you need if you've upgraded your battery to a 60V battery. The peak power is set to 6500W. You'll get above 40mph, and more power and acceleration by uploading this flash.

WARNING: Danger to motor.

SUPER73 LEGACY SERIES (2025+)

48V STOCK

Last updated: 8/8/25

This section is for the following setup:

  • BAC855
  • Stock motor
  • Stock battery

DOWNLOAD 48V STOCK

If you've only installed the BAC855, this flash is for you. It is the flash that is pre-loaded on a BAC855 for ANY Legacy bike with motor serial numbers ending in:

-031

-021

P-51 BULLET/ACE

48V STOCK BAC855

Last updated: 8/14/24

This section is for the following setup:

  • BAC855
  • Stock motor
  • Stock battery

DOWNLOAD 48V STOCK

If you've only installed the BAC855, this flash will work for you.

60V UPGRADE BAC855

Last updated: 10/15/25

This flash is for the following setup:

  • BAC855
  • Stock motor
  • 60V battery, 75A max current

DOWNLOAD 60V

This is the flash you need if you've upgraded your battery to a 60V battery. The peak power is set to 6500W. You'll get above 40mph, and more power and acceleration by uploading this flash.

48V STOCK BAC2000

Last updated: 1/19/25

This flash is for the following setup:

  • BAC855
  • Stock motor
  • Stock battery

DOWNLOAD 48V BAC2000 (BULLET)

This is the flash you need if you're running a BAC2000 with the stock motor and stock Bullet battery.

DOWNLOAD 48V BAC2000 (ACE)

This is the flash you need if you're running a BAC2000 with the stock motor and stock Ace battery.

60V UPGRADE BAC2000

Last updated: 9/17/25

This flash is for the following setup:

  • BAC855
  • Stock motor
  • 60V battery, 75A max current

DOWNLOAD 60V BAC2000

This is the flash you need if you've upgraded your battery to a 60V battery. The peak power is set to 6500W. You'll get above 40mph, and more power and acceleration by uploading this flash.

ZOOZ

UU750

Last updated: 9/7/24

This flash is for the following setup:

  • BAC855
  • Stock motor
  • Stock battery

DOWNLOAD STOCK UU750 FLASH

This is the flash you need if you have a stock Zooz UU750, upgraded with our BAC855. This flash comes on the BAC855 kit when shipped.

UU750 52V

Last updated: 12/04/24

This flash is for the following setup:

  • BAC855
  • Stock motor
  • Hi-output 52V battery

DOWNLOAD UU750 52V FLASH

This is the flash you need if you have a Zooz UU750, upgraded with our BAC855, AND a hi-output 52V battery (>50A continuous output).

UU1100

Last updated: 9/7/24

This flash is for the following setup:

  • BAC855
  • Stock motor
  • Stock battery

DOWNLOAD STOCK UU1100 FLASH

This is the flash you need if you have a stock Zooz UU1100, upgraded with our BAC855. This flash comes on the BAC855 kit when shipped.

UU1100 60V

Last updated: 8/25/25

This flash is for the following setup:

  • BAC855
  • Stock motor
  • 60V hi-output battery

DOWNLOAD UU1100 60V FLASH

If you upgraded to a BAC855 and have a hi-output 60V battery (>60A continuous), then use this flash. BE WARNED that Zooz motors have no temperature sensors, and will overheat even in a stock powertrain. Temperature management (not riding too hard for too long) is your responsibility!

UF1200

Last updated: 8/13/25

This flash is for the following setup:

  • BAC855
  • Stock motor
  • Stock battery

DOWNLOAD STOCK UF1200 FLASH

This is the flash you need if you have a stock Zooz UF1200, upgraded with our BAC855. This flash comes on the BAC855 kit when shipped.

UF1200 60V

Last updated: 8/25/25

This flash is for the following setup:

  • BAC855
  • Stock motor
  • 60V high output battery

DOWNLOAD 60V UF1200 FLASH

This is the flash you need if you have a stock Gen1 Zooz UF1200, upgraded with our BAC855 and a high-output 60V flash. Danger to the stock motor.

Ultra Urban (2025)

Last updated: 6/17/25

This flash is for the following setup:

  • BAC855
  • Stock motor
  • Stock battery

DOWNLOAD STOCK UU FLASH

This is the flash you need if you have a stock Gen4 Zooz Ultra Urban, upgraded with our BAC855.

Ultra Ripster (2025)

Last updated: 2/26/25

This flash is for the following setup:

  • BAC855
  • Stock motor
  • Stock battery

DOWNLOAD STOCK UR FLASH

This is the flash you need if you have a stock Zooz Ultra Ripster, upgraded with our BAC855.

UltraFlex (2025)

Last updated: 11/17/25

This flash is for the following setup:

  • BAC855
  • Stock motor
  • Stock battery

DOWNLOAD STOCK UF FLASH

This is the flash you need if you have a stock Gen2 Zooz UF, upgraded with our BAC855.
